All green on GitHub

Posted on 2023-10-01 09:14 +0100 in Coding • Tagged with GitHub • 2 min read

In about a week's time I'll have had a GitHub account for 15 years! I can't even remember what motivated me to create one now, but back in October 2008 I grabbed the davep account...

Making my account

...and then made my first repo.

First repo made

My use of the site after that was very sporadic. It looks like I'd add or update something once or twice a year, but I wasn't a heavy user.

First few years

Then around the middle of 2015 I seem to have started using it a lot more.

The next few years

This very much shows that during those years I was working on personal stuff that I was making available in case anyone found it useful, but also leaning heavily on GitHub as a (a, not the) place to keep backups of code I cared about (or even no longer cared about). Quite a lot of that green will likely be me having a few periods of revamping my Emacs configuration.

The really fun part though starts about a year ago:

Working on FOSS full time

It's pretty obvious when I started working at Textualize, and working on a FOSS project full time. This is, without a doubt, the most green my contribution graph has looked. It looks like there's a couple of days this year where I haven't visited my desk at all, and I think this is a good thing (I try really hard to have a life outside of coding when it comes to weekends), but I'm also delighted to see just how busy this year looks.

I really hope this carries on for a while to come.

Apparently, as of the time of writing, I've made 12,588 contributions that are on GitHub. What's really fun is the fact that my first contribution pre-dates my GitHub account by 9 years!

My very first contribution

This one's pretty easy to explain: this is back from when I was involved with Harbour. Back then we were using SourceForge to manage the project (as was the fashion at the time), and at some point in the past whoever is maintaining the project has pulled the full history into GitHub.

My contribution history on GitHub is actually older than my adult son. I suspect it's older than at least one person I work with. :-/ 1

  1. I'm informed that this isn't the case2; apparently I'm either bad at estimating people's ages, or bad at remembering them; or both.

  2. Although it's not too far off. :-/

Website: Miscellaneous Stuff moved

Posted on 2023-08-14 22:04 +0100 in Coding • Tagged with html, web • 2 min read

This evening I've spent more time working on the planned complete remake of my personal website, in this case "porting" over many of the files that made up the old "miscellaneous stuff" section of the site. If I'm honest, most if not all of the things in there are no longer relevant (like: who really needs a shell script to make gnuplot plots from files pulled off a 1990s-era Garmin handheld GPS unit?), but I thought I'd keep them kicking around "just in case".

One wee section I wasn't going to get rid of though was my scans of three pages from a UK magazine called Personal Computer News. These contain Grid Bike; a game I wrote for the VIC-20, all in BASIC, and got published. For my efforts I got a huge cheque for £40! If that doesn't seem like much to you, trust me, to 1983 me this was huge.

I bought a 16k RAM pack with the money.

Funnily enough, while trying to improve some of the links in the text, I decided to see if there was now an archive online somewhere and, sure enough, there is: in the obvious place. This means that my web site isn't the only copy of my program on the net. If you go to the December 21st 1983 edition and turn to around page 84, there I am!

The cover of PCN

At this point I'm almost tempted to try and get an emulator up and running and get the code going again. How much fun would it be to add a video to my YouTube channel, of me playing one of the very first games I wrote?

Website: Norton Guide information moved

Posted on 2023-08-13 10:02 +0100 in Coding • Tagged with html, web • 2 min read

This morning I've spent a wee bit of time tinkering with the configuration of the planned complete remake of my personal website. As part of this I made an effort to "port" over a section of the site. The choice for the first section to move was easy enough: Norton Guides.

Of all the parts of my old site, this is probably the most useful in terms of "contains information that isn't generally available out there on the web elsewhere and some folk might find it useful". I mean, at some point in the past, someone edited the Wikipedia page for Norton Guides and linked to mine as a source.

So getting that one back up and running as soon as possible made sense.

I've not added every bit of Norton Guide code to the main page, instead just pulling over and tidying up what was there before. On the other hand, just hacking on Markdown makes it all so much easier so I may expand on it a bit.

The really important part was moving over the file format details. This, I feel, is the information that people will be looking for, if anyone is ever looking.

So, proper start made; there's content beyond the landing page. There's still a lot to weed out and move over, and I think there's a lot of tweaking and the like with the configuration to do too. But the ball is rolling now. Ever time I get a spare hour and the desire to sit at my desk I can pick a section, look it over, decide if it deserves to come over, and act on that.

Heck, at this rate I might even end up with an actively-maintained website again!

The reboot begins

Posted on 2023-08-11 13:19 +0100 in Coding • Tagged with html, web • 2 min read

And I'm off! This morning I spent a good amount of time going through the sources for the old version of and removing everything that won't be needed any more, and also building up a rough TODO list of things I may want to recreate as content.

With that done, as mentioned earlier today, I started work on building the site around Pelican. Pretty quickly though I started to feel that that was going to be a bad choice. While Pelican felt like a perfect fit for this blog -- mainly because it seems to be very blog-oriented -- it was feeling a bit clunky for a general website that would have a handful of static pages at best; likely something I wouldn't be updating too often.

So I put it aside and went on with my morning, doing normal Friday domestic stuff like the weekly supermarket shop. It was while I was out doing that that I realised the obvious answer: use what we use for the Textual docs and what's been used for Material for MkDocs!

I've just spent about 40 minutes after lunch kicking that off and it was really straightforward. Of course the result is horrifically cookie-cutter in terms of its look -- such is the way that mkdocs-material sites end up looking out of the box -- but I don't much care about that; what's important is that I've got a placeholder page in place, and I've quickly built a framework for writing and publishing the content.

So that's the plan: now that the welcome page is in place and there's something on my domain that looks like a working website again I can start to slowly drag in old content in a new format. Heck, if I'm careful I might even be able to retain some of the old URLs!

Longer-term plans might involve finally sorting out https support (yes, even today, my site is http-only), and perhaps adding some sort of RSS feed so there's a record of when changes are made.

After that... hopefully that'll be about it and perhaps the website will last another 22 years running on top of the same engine (actually that part should be easier because the "engine" is now local and it generates a static site).

The question then becomes who'll last longer, the site or me?

Admitting defeat on my website

Posted on 2023-08-11 08:44 +0100 in Coding • Tagged with php, html, web • 2 min read

I've had since very late 1999. Initially it started as a domain used just for email; while I did have a website, around that time it was still hosted on my then-ISPs hosting service, with a mirror on a friend's web server.

A year or so later I finally did a proper revamp of my website and finally settled on as the place to point people to. I think, when I made that move, that's when I decided to write my own website engine in php. It was fun. It worked. I didn't want to code backend stuff (I don't think the backend vs frontend distinction was even a thing we were talking about then) so hacking it together in an unholy mix of ruby to generate various static files that live in the filesystem and then php to turn them into actual HTML made sense.

And it worked.

The earliest version of I can find

I heavily maintained the site for many years; keeping the same engine, tweaking the styles, adding features and content. I figure some time around 2013 or 2014 I probably stopped being quite so active in messing with it, and then in the last 5 or 6 years I've pretty much neglected it.

The neglect shows.

Meanwhile... php has changed. Quiet a lot. It's one of those languages I used back in the day and pay no attention to. Then earlier this week I noticed that there must have been an update on the host and huge parts of my site broke, lots of content missing, pretty much useless and dead in the water.

I did briefly think about breaking out the latest and greatest php locally, setting things up to investigate what's going on, and seeing if I could breathe some more life into it; but really what's the point?

So after all these years I'm finally admitting defeat.

Right now, on the home page, I've just got a placeholder saying that bitrot finally ate my website and that I'm going to start again from scratch. That's my plan: given that I had a good experience moving this blog over to Pelican I think I'm going to build a new with Pelican. Where possible I'll try and drag some of the old content over, but I'm also going to use this opportunity to have a proper digital spring clean.

There's no planned timescale for this, but this morning I've spent an hour or so over coffee, branching the repo for the site and pruning out all the stuff I know I won't need and don't want.

I'll try and drop the odd update in here as things progress.

A new GitHub profile README

Posted on 2023-07-03 08:15 +0100 in Coding • Tagged with GitHub, Python, Textual • 2 min read

My new GitHub banner

Ever since GitHub introduced the profile README1 I've had a massively low-effort one in place. I made the repo, quickly wrote the file, and then sort of forgot about it. Well, I didn't so much forget as just keep looking at it and thinking "I should do something better with that one day".

Thing is, while there are lots of fancy approaches out there, and lots of neat generator tools and the like... they just weren't for me.

Then yesterday, over my second morning coffee, after getting my blog environment up and going again, I had an idea. It could be cool to use Textual's screenshot facility to make something terminal-themed! I mean, while it's not all I am these days, so much of what I'm doing right now is aimed at the terminal.

So... what to do? Then I thought it could be cool to knock up some sort of login screen type thing; with a banner. One visit to an online large terminal text generator site later, I had some banner text. All that was left was to write a simple Textual application to create the "screen".

The main layout is simple enough:

def compose(self) -> ComposeResult:
    yield Label(NAME, classes="banner")
    yield Label(PRATTLE)
    yield Label(" login: [reverse] [/]")

where NAME contains the banner and PRATTLE contains the "login message". With some Textual CSS sprinkled over it to give the exact layout and colour I wanted, all that was left was to make the snapshot. This was easy enough too.

While the whole thing isn't fully documented just yet, Textual does have a great tool for automatically running an application and interacting with it; that meant I could easily write a function to load up my app and save the screenshot:

async def make_banner() -> None:
    async with GitHubBannerApp().run_test() as pilot:"davep.svg")

Of course, that needs running async, but that's simple enough:

if __name__ == "__main__":

Throw in a Makefile so I don't forget what I'm supposed to run:

.PHONY: all
    pipenv run python

and that's it! Job done!

From here onward I guess I could have some real fun with this. It would be simple enough I guess to modify the code so that it changes what's displayed over time; perhaps show a "last login" value that relates to recently activity or something; any number of things; and then run it in a cron job and update the repository.

For now though... I'll stick with keeping things nice and simple.

  1. It was actually kind of annoying when they introduced it because the repo it uses is named after your user name. I already had a davep repo: it was a private repo where I was slowly working on a (now abandoned, I'll start it again some day I'm sure) ground-up rewrite of my website.

Build in public, even in private

Posted on 2022-10-06 10:44 +0100 in Coding • Tagged with coding • 4 min read

As mentioned yesterday, I'm about to start working at Textualize, and building Open-source software is important to the company. Will -- the CEO -- is all about building in public. If you follow him on Twitter you'll notice that his Python coding adventure tweets actually outnumber is cooking tweets!

As someone who has long been a supporter of and fan of Free Software and Open-source software, and has made some small contributions along the way, I've also always made a point of building my own tools in public. In most cases they're things that are likely only helpful to me, but some are more generally useful. The point being though: it's all there in case it's helpfull to someone else.

Which means that, as much as possible, when I'm writing code, I write it as if it's going to be visible in public and someone else is going to be reading it. I try and make the code tidy. I try and comment it well. I try (but don't always manage for personal projects) to fully document it. The important thing here being that someone coming to the code fresh should be able to follow what's going on.

Against that background, and having just gone through the process of handing off almost 5 years of work to someone else as a left an employer, I got to thinking: we should always "build in public", even if it's in private.

When I started with my previous employer, and even to the day I left, I was the only software developer there. I worked with a team who wrote code, but being software developers wasn't what they did. Bioinformaticians and machine learning scientists have other things to be doing. But, as I wrote my code, I wrote every line assuming they, or some other developer down the line, would be reading it. Pretty much every line was written for an audience I couldn't see and didn't fully know. This, as mentioned above, meant trying to keep the code clean, ensuring it was commented in helpful ways, ensuring the documentation was helpful, and so on.

But it wasn't just about the code. Any non-trivial system will have more to it than code. We had an internal instance of GitLab and I tracked all of my work on there. So, as I planned and worked on new features, or went on bug hunts, I'd document the process in the issue tracker. As much as possible I'd be really verbose about the process. Often I wouldn't just open an issue, go work on it, and then mark it closed; as I worked through the issue I'd add comment after comment under it, documenting my thinking, problems, solutions, cite sources when looking something up, that sort of thing.

The whole process was an act in having a conversation with current or future team members if they ever needed to look; with future me (really, that helped more than once -- we all have those "that the hell was I thinking?" moments); with any developer(s) who took over from me in the future.

I did all this as if I was broadcasting it in public on Twitter or on GitHub, etc. It was in private, of course, but I approached it as if it was in public.

There were always three main reasons for this, I felt:

  1. Accountability. At any moment someone who I worked with could review what I was doing and why I was doing it; it was an invitation to anyone curious enough to talk with me about what I was building and how I was building it.
  2. Continuity of support for unplanned reasons. Life happens, sometimes you may, unplanned, never be available at work again. I never wanted to leave my employer in a position where picking up from such an event was a nightmare.
  3. Continuity of support for planned reasons. It was possible, and it became inevitable, that I'd move on to something else. If that was to happen I wanted to be sure that whoever picked up after me would be able to do so without too much effort.

In the end item 3 seemed to really pay off. When it came time for me to hand over my work to someone else, as I left, the process was really smooth and trouble-free. I was able to point the developer at all the documentation and source code, at all the issues, and invite them to read through it all and then come back to me with questions. In terms of time actually spent talking about the main system I was handing over I'd say that 4 years of work was handed over with just a few hours of actual talking about it.

It remains to be seen if it really paid off, of course. If they get really stuck they do have an open invitation to ping me a question or two; I care enough about what I designed and built that I want it to carry on being useful for some time to come. But... I like to think that all of that building in public, in private, will ensure that this is an invitation that never needs to be called on. I like to think that, if something isn't clear, they'll be able to check the code, the documentation and the issue history and get to where they need to go.

Reading 2bit files (for fun) - the sequence

Posted on 2020-09-26 15:57 +0100 in Coding • Tagged with Bioinformatics • 5 min read


This post will cover the most important content of a 2bit file: the actual sequence data itself. In the first post I wrote about the format of the file's header, and in the second post I wrote about the content of the file's index.

At this point that's enough information to know what's in the file and where to find it. In other words we know the list of sequences that live in the file, and we know where each one is positioned within the file. So, assuming we have our index in memory (ideally some sort of key/value store of sequences names and their offsets in the file), given the name of a sequence we can know where to go in the file to load up the data.

So the next obvious question is, what will we find when we get there? Actual sequence data is stored like this:

Content Type Size Comments
DNA size Integer 4 bytes Count of bases in the sequence
N block count Integer 4 bytes Count of N blocks in the sequence
N block starts Integer Array 4*count bytes Positions are zero-based
N block sizes Integer Array 4*count bytes
Mask block count Integer 4 bytes Count of mask blocks in the sequence
Mask block starts Integer Array 4*count bytes Positions are zero-based
Mask block sizes Integer Array 4*count bytes
Reserved Integer 4 bytes Should always be 0
DNA data Byte Array See below

Breaking the above down:

N blocks

As mentioned in passing in the first post: technically it's necessary to encode 5 different characters for the bases in the sequences. As well as the usual T, C, A and G, there also needs to be an N, which means the base is unknown. Now, of course, you can't pack 5 states into two bits, so the 2bit file format solves this by having an array of block positions and sizes where any data in the actual DNA itself should be ignored and an N used in its place.

Mask blocks

This is where my ignorance of bioinformatics shows, and where it's made very obvious that I'm a software developer who likes to muck about with data and data structures, but who doesn't always understand why they're used. I'm actually not sure what purpose mask blocks serve in a 2bit file, but they do affect the output. If a base falls within a mask block the value that is output should be a lower-case letter, rather then upper-case.

The DNA data

So this is the fun bit, where the real data is stored. This should be viewed as a sequence of bytes, each of which contains 4 bases (except for the last byte, of course, which might contain 1, 2 or 3 depending on the size of the sequence).

Each byte should be viewed as an array of 2 bit values, with the values mapping like this:

Binary Decimal Base
00 0 T
01 1 C
10 2 A
11 3 G

So, given a byte whose value is 27, you're looking at the sequence TCAG. This is because 27 in binary is 00011011, which breaks down as:

00 01 10 11

How you pull that data out of the byte will depend on the language and what it makes available for bit-twiddling; those that don't have some form of bit field will probably provide the ability to bit shift and do a bitwise and (it's also likely that doing bitwise operations is better than using bit fields anyway). In the version I wrote in Emacs Lisp, it's simply a case of shifting the two bits I am interested in over to the right of the byte and then performing a bitwise and to get just its value. So, given an array called 2bit-bases whose content is this:

(defconst 2bit-bases ["T" "C" "A" "G"]
  "Vector of the bases.

Note that the positions of each base in the vector map to the 2bit decoding
for them.")

I use this bit of code to pull out the individual bases:

(aref 2bit-bases (logand (ash byte (- shift)) #b11))

Given code to unpack an individual byte, extracting all of the bases in a sequence then becomes the act of having two loops, the outer loop being over each byte in the file, the inner loop being over the positions within each individual byte.

In pseudo-code, assuming that start and end hold the base locations we're interested in and dna_pos is the location in the file where the DNA starts, the main loop for unpacking the data looks something like this:

# The bases.
bases = [ "T", "C", "A", "G" ]

# Calculate the first and last byte to pull data from.
start_byte = dna_pos + floor( start / 4 )
end_byte   = dna_pos + floor( ( end - 1 ) / 4 )

# Work out the starting position.
position = ( start_byte - dna_pos ) * 4

# Load up the bytes that contain the DNA.
buffer = read_n_bytes_from( start_byte, ( end_byte - start_byte ) + 1 )

# Get all the N blocks that intersect this sub-sequence.
n_blocks = relevant_n_blocks( start, end )

# Get all the mask blocks that interest this sub-sequence.
mask_blocks = relevant_mask_blocks( start, end )

# Start with an empty sequence.
sequence = ""

# Loop over every byte in the buffer.
for byte in buffer

  # Stepping down each pair of bits in the byte.
  for shift from 6 downto 0 by 2

    # If we're interested in this location.
    if ( position >= start ) and ( position < end )

      # If this position is in an N block, just collect an N.
      if within( position, n_blocks )
        sequence = sequence + "N"

        # Not a N, so we should decode the base.
        base = bases[ ( byte >> shift ) & 0b11 ]

        # If we're in a mask block, go lower case.
        if within( position, mask_blocks )
          sequence = sequence + lower( base )
          sequence = sequence + base



    # Move along.
    position = position + 1



Note that some of the detail is left out in the above, especially the business of loading up the relevant blocks; how that would be done will depend on language and the approach to writing the code. The Emacs Lisp code I've written has what I think is a fairly straightforward approach to it. There's a similar approach in the Common Lisp code I've written.

And that's pretty much it. There are a few other details that differ depending on how this is approached, the language used, and other considerations; one body of 2bit reader code that I've written attempts to optimise how it does things as much as possible because it's capable of reading the data locally or via ranged HTTP GETs from a web server; the Common Lisp version I wrote still needs some work because I was having fun getting back into Common Lisp; the Emacs Lisp version needs to try and keep data as small as possible because it's working with buffers, not direct file access.

Having got to know the format of 2bit files a fair bit, I'm adding this to my list of "fun to do a version of" problems when getting to know a new language, or even dabbling in a language I know.

Reading 2bit files (for fun) - the index

Posted on 2020-09-05 10:59 +0100 in Coding • Tagged with Bioinformatics • 4 min read

As mentioned in the first post, once you've read in the header data for a 2bit file, the next step is to read the index. This is an index into all the different sequences held in the file. Reading the index itself is fairly straightforward.

The index comes right after the header -- so it starts on the 17th byte of the file. Each entry in the index contains three items of information:

Content Type Size Comments
Name length Integer 1 byte How many bytes long the name is
Name String Varies Length given by previous field
Offset Integer 4 bytes Location in the file of the sequence

So, in some sort of pseudo-code, you'd read in the index as follows:

index = dict()
for seq = 1 to seq_count // seq_count comes from the header
  name_len = (int) read_bytes( 1 )
  name     = (string) read_bytes( name_len )
  offset   = (int) read_bytes( 4 )
  index[ name ] = offset

Note, as mentioned in the first post, the index will need to be byte-swapped if the file is in an endian form other than the machine you're running your code on. How you'd go about this will, of course, vary from language to language, but the main idea is always going to be the same.

There's a fairly striking downside to this approach though: reading data can often be an expensive (in terms of time) operation -- this is especially true if the data is coming in from a remote machine, perhaps even one that's being accessed over the Internet. As such, it's best if you can make as few "trips" to the file as possible.

With this in mind, the best thing to do is to read the whole index into memory in one go and then process it from there -- the idea being that that's just one trip to the data source. The problem here, however, is that there's nothing in the header or the index that tells you how large the index actually is. What you can do though is work on the worst case scenario (assuming memory will allow). The worst case is fairly easy to handle: it's going to be 1 byte for the name length, plus 255 bytes for the name (the longest possible name), plus 4 bytes for the offset; multiply all that by the number of sequences in the index and you have the worst-case buffer size.

When reading this data in you might also want to ensure you're not going to run off the end of the file (perhaps the names are all quite small and so are the sequences).

Recently I've been working on a package for Emacs that can read data from 2bit files, so here's the core code for reading in the index:

(defun 2bit--read-index (source)
  "Read the sequence index from SOURCE.

As a side effect `2bit-data-pos' of SOURCE will move."
   ;; The index will be a hash of sequence names, with the values being the
   ;; offsets within the file.
   with index = (make-hash-table :test #'equal)
   ;; We could read each name/value pair one by one, but because we're doing
   ;; this within Emacs, which means making a temp buffer for every read,
   ;; that could get pretty expensive pretty fast. So instead we'll read the
   ;; index data in in one go. However, there is no easy-to-calculate size
   ;; for the index. The best we can do is calculate the worst case size. So
   ;; let's do that. The worst case size is the maximum size of the name of
   ;; a sequence (255), plus the size of the byte that tells us the name
   ;; (1), plus the size of the word that is the offset in the file (4).
   with buffer = (2bit--read source (* (2bit-data-sequence-count source) (+ 255 1 4)))
   ;; For every sequence in the file...
   for n from 1 to (2bit-data-sequence-count source)
   ;; Calculate the position within the buffer for this loop around. Note
   ;; that the skip is the last position plus 1 for the size byte plus the
   ;; size plus the length of the offset word.
   for pos = 0 then (+ pos 1 size 4)
   ;; Get the length of the name of the sequence.
   for size = (aref buffer pos)
   ;; Pull out the name itself.
   for name = (substring buffer (1+ pos) (+ pos 1 size))
   ;; Pull out the offset.
   for offset = (2bit--word-from-bytes source (substring buffer (+ pos 1 size) (+ pos 1 size 4)))
   ;; Collect the offset into the hash.
   do (setf (gethash name index) offset)
   ;; Once we're all done.... return the index.
   finally return index))

This code does what I mention above: it grabs enough data into a buffer in one go that I'll have the whole index in memory to pull apart, and then I work with the in-memory copy. The index is added to a hashing dictionary. Note that, in this case, I don't actually do the test for running off the end of the file because at the heart of the file reading code is insert-file-contents-literally and it doesn't error if you request too much.

With that done you'll have a list of all the sequences in the file. The next part, which will come in the next post, is the properly tricky part: the decoding of the sequence data itself.

Reading 2bit files (for fun)

Posted on 2020-08-30 15:20 +0100 in Coding • Tagged with Bioinformatics • 6 min read


I've written a bit before about the value of having simple but interesting "problems", that you know the solution to, as a way of exercising yourself in a new environment. Recently I've added another to the list I already have, and I used it as an excuse to get back into writing some Common Lisp; and then went on to use it as a reason to write yet another package for Emacs.

Having gone through the process of writing code to handle 2bit files twice in about a month, and in two very similar but slightly different languages, I thought it might be interesting for me to then use it to exercise my ability to write blog posts (something I always struggle with -- I find writing very hard on a number of levels) and especially posts that explain a particular problem and how I implemented code relating to that problem.

Also, because the initial version of this post rambled on a bit too much and I lost the ability to finish it, I'm starting again and will be breaking it up a number of posts spanning a number of days -- perhaps even weeks -- so that I don't feel too overwhelmed by the process of writing it. I will, of course, make sure every post links to the other posts.

Now, before I go on, I'll make the important point that everything here is written from the perspective of a software developer who happens to work as part of a bioinformatics team; I don't do bioinformatics, I don't claim to understand it, I just happen to sit with (well, used to sit with them -- hopefully we'll all make it back to the office one day!) and work with them, and develop software that supports their work. Anything you see in any of the posts that's wrong about that subject: that's just my ignorance being shown through the lens of a software developer (all corrections are welcome).

So, with all those disclaimers aside, I'm going to go on a slow wander through what a 2bit file is, how you'd go about reading it, and related issues. This isn't designed as a tutorial or anything like that, this is simply me taking what I've learnt and writing it down. Perhaps someone else will benefit one day, but the purpose is to simply enjoy cementing it in my own mind and to enjoy the process of putting it all in writing.

What is a "2bit file"?

So what's this new "problem" I've added to my list? It's code to read sequence data from 2bit format files. For anyone who doesn't know (bioinformatics people look away now; a software developer is going to explain one of your file formats), this is a file format that is intended to hold sequences in an efficient way. As I'm sure you know, DNA is made up of 4 bases, represented by the letters T, C, A and G. So, in the simplest case, we could just represent a genome using those four letters. Simple enough, right? Nice big text file with just those 4 letters in?

The thing is, something like the human genome is around 3 billion bases in length. That'd make for a petty big file to have to store and move around. So why not compress it down a bit? That's where the 2bit format comes in.

Given this problem I'm sure most developers would quickly notice that, given 4 different characters, you only need 2 bits to actually hold them all (two bits gets us 00, 01, 10 and 11, so four different states). This means with a little bit of coding you can store 4 bases in a single byte. Just like that you've pretty much squished the whole thing down to 1/4 of the original size. And that's more or less what the 2bit format does. If you take a look at the actual data for the human genome you'll see that hg38.2bit is roughly 1/4 of 3 billion bytes, ish, give or take.

There is a wrinkle, however. There are parts of a genome where you might not know what base is there. Generally an N is used for that. So, actually, we want to be able to store 5 different characters. But 5 isn't going to go into 2 bits... Damn! Well, it's okay, 2bit has a solution to that too, and I'll cover that later on.

How is a 2bit file formatted?

As you can see from the format information available online, a 2bit file is a binary file format that is split into 3 key parts:

  • A fixed size header with some key information
  • An index into the rest of the file
  • A series of records that contain actual sequence information

In this first post I'll cover the details of the header. Subsequent posts will cover the index and the actual sequence data records.

The header

The header of a 2bit file is fixed in size and contains some key information. It can be broken down as follows:

Content Type Size Comments
Signature Integer 4 bytes See below for endian issues.
Version Integer 4 bytes Always 0.
Sequence count Integer 4 bytes
Reserved Integer 4 bytes Always ignored.

The signature value is used to test if what you're looking at is a 2bit file, but also tells you some vital information about how to read the file -- see below for more on that. The version value is always 0 -- as such another useful test would be to error out if you get a valid signature but get a version other than 0. The sequence count is, as you'd guess, the number of sequences that are held within the file -- this is important when loading in the index of the file (more on that in the next post).

The signature, big and little endianness, and byte swapping

The header mentioned above comprises of 4 32-bit word values. The very first word is important to how you read the rest of the file. This is the signature for the 2bit file and it should always be 0x1A412743. And this is where it gets interesting and fun right away. The 2bit file format allows for the fact that the file can be built in either a little-endian or a big-endian machine, and the 32-bit word values can be binary-written to the file in the local architecture's byte order. The effect of this is that, from reading the very first value in the file, you need to decide if every other numeric value you read needs to be byte-swapped in some way. The early logic being (in no particular language) something like:

if signature == 0x1A412743 then
  must_swap = False
else if byte_swap( signature ) == 0x1A412743 then
  must_swap = True
  raise "This isn't a valid 2bit file"

Simply put, to read the rest of the file you will need a function that byte-swaps a 32bit numeric value, and a flag of some sort to mark that you need to do this every time you read such a value. Of course, depending on your language of choice, you could do it in a number of different ways. In a language like JavaScript or Scheme, where you can easily throw around functions, I'd probably just assign the appropriate 32bit-word-reading function to a global function name and call that regardless throughout the rest of the code. In other languages I'd probably just check the flag each time and call the swapping function if needed. In something like Python I'd likely just use the signature to decide on which format to pass to struct.unpack. For example, some variation on:

# Assuming that 'header' is the whole header of the file read as a binary buffer.

word_fmt = ""

for test_fmt in ( "<I", ">I" ):
    if struct.unpack( test_fmt, header[ 0:4 ] )[ 0 ] == 0x1A412743
        word_fmt = test_fmt

if not word_fmt:
    raise Exception( "This isn't a 2bit file" )

Now, the Python approach sort of hides the important detail here. With it we'd simply use struct.unpack's ability to handle different byte orders and not worry about the detail. Which isn't fun, right? So how might code to byte-swap a 32bit value look?

Assuming you've got the value as an actual numeric integer, it can be as simple as using a bit of bitwise anding and shifting. Here's the basic code I wrote in Common Lisp, for example:

(defun swap-long (value)
  "Swap the endianness of a long integer VALUE."
   (logand (ash value -24) #xff)
   (logand (ash value -8) #xff00)
   (logand (ash value 8) #xff0000)
   (logand (ash value 24) #xff000000)))

JavaScript might be something like:

function swapLong( value ) {
    return ( ( value >> 24 ) & 0xff       ) |
           ( ( value >>  8 ) & 0xff00     ) |
           ( ( value <<  8 ) & 0xff0000   ) |
           ( ( value << 24 ) & 0xff000000 )

and other variations on that theme in different languages.

Up next

In the next post I'll write about how the sequence index is stored and how to load it, including some considerations about how to make the loading as efficient as possible.
